About
5
2
Comapct Ethernet Board
Function
The Compact Ethernet Board is a module, designed for connection
of
7106, 7206 and 7010 Series printer to LAN.
It is a good and economical solution of this purpose.
The module firmware allows a quick and easy adaptation to the user's local network
(LAN).
Main view
¢
LAN Interface
£
Button (pressing this button causes the printing current printer's network settings)
¤
Connector to the printer
¢
£
¤
