Condux Slip Clutch Capstan - Manual (Page 9)

9
B. PARTS LIST
Condux 30” Slip Clutch Capstan
08760030
ITEM PART NO. DESCRIPTION QTY
1 02102001 FLATWSHR 0.25 TYPE A-NARR ST CZ 24
2 02197600 CAPSRW 0.25-20X2.25 HHSTGR5 CZ 12
3 02246400 LABEL, CALIBRATION 1
4 02264400 LABEL, MAX CAPACITY 1,000 LBS 1
5 02269607 LABEL, WARNING-READ MAN 1.5X4.5 1
6 02269610 LABEL, WARNING-CBLE TENSN 1.5X3.0 1
7 02269617 LABEL, WARNING-CPSTN PNCH 1.5X3.0 1
8 02269618 MACSRW #10-32X0.62 SF BR 16
9 02269640 BEARING, SLV 2.003-2.379-1.125 1
10 08760010 RING, MOUNT (WELD) 30" SLIP CLTCH 1
11 08760012 PLATE, CLUTCH (INNER)-SLIP CLUTCH 2
12 08760016 CAPSTAN, 30" WELD-SLIP CLUTCH 1
13 12013700 NUT 0.25-20 NYLOC ST GR2 CZ 12
ITEM PART NO. DESCRIPTION QTY
1 00209800 CABLE .048-7X7 GAL AIRCRAFT ST 1 FT
2 02211300 CRIMPING SLEEVE .048 COPPER 1
3 02251800 PIN, SPRING-SLOTTED .125-2.000 2
4 02260500 SPRING, COMPRESS .120-1.095-4.50 1
5 02269641 PIN, SPRING-SLOTTED .156-2.500 1
6 02269642 WASHER, BELLEVILLE 2.010-4.920 1
7 02269644 LABEL, WARN-RMVE SFTY WIRE 2.8" 1
8 02269759 LABEL, CALIBRATION LOAD 1
9 02269761 TIE, MARKER-18 IN-HEAVY DUTY 1
10 08675108 CAP, SPRING-CAPSTAN-FO PULLER 1
11 08760001 CAP, END (SHAFT)-SLIP CLUTCH 1
12 08760003 PLATE, FRICTION ASSY-SLIP CLUTCH 2
13 08760008 SHAFT, CAPSTAN HUB (WELD) 1
14 08760009 NUT, LOCK (SHAFT)-SLIP CLUTCH 1
15 08760011 CAPSTAN, 30" BODY ASSY 1
16 08760014 RING, SPACER-SLIP CLUTCH 1
17 12023300 SETSCREW, .250-20-.50-HXSO-PL 2
