B. PARTS LIST
Condux 42” Slip Clutch Capstan
08760040
ITEM PART NO. dESCRIPTION QTY
1 02102000 FLATWSHR 0.25 TYPEA-WIDE ST CZ 40
2 02182301 CAPSRW 0.37-16X1.00 CSSTALY CZ 16
3 02197600 CAPSRW 0.25-20X2.25 HHSTGR5 CZ 20
4 02246400 LABEL, CALIBRATION 1
5 02264400 LABEL, MAX CAPACITY 1000 LBS 1
6 02269607 LABEL,WARNING-READ MAN 1.5X4.5 1
7 02269610 LABEL,WARNING-CBLE TEN 1.5X4.5 1
8 02269617 LABEL,WARNING-CPSTN 1.5X4.5 1
9 08760036 BEARING,SLV 2.379-2.753-2.00 1
10 08760037 PLATE,50-42 CLUTCH(INNER)-SLIP 2
11 08760052 CAPSTAN,WELD 42" X 8" SLIP 1
12 08760054 BODY,CAP 42X8 (WELD) SLIP CLTH 1
13 12006100 NUT 0.25-20 HEX ST GR2 CZ 20
ITEM PART NO. dESCRIPTION QTY
1 02211300 CRIMPING SLEEVE .048 COPPER 1
2 02251800 PIN,SPRING-SLOTTED .125-2.000 2
3 02256400 LABEL,SERIAL NUMBER 1.50 X3.00 1
4 02260500 SPRING,COMPRSS .135-1.095-4.50 1
5 02269641 PIN,SPRING-SLOTTED .156-2.500 1
6 02269644 LABEL,WARN-RMVE SFTY WIRE 2.8" 1
7 02269759 LABEL, CALIBRATION LOAD 1
8 02269761 TIE,MARKER-18 IN-HEAVY DUTY 1
9 08675108 CAP,SPRING-CAPSTAN-FO PULLER 1
10 08760032 RING, SPACER-SLIP CLTCH 50-42" 1
11 08760033 SHAFT,50-42 CAPSTAN HUB (WELD) 1
12 08760035 PLATE,50-42 FRICTN ASSY- CLTCH 2
13 08760043 WASHER,BELLEVILLE 2.40-4.92 1
14 08760044 NUT,LOCK (SHAFT) 50-42" CLUTCH 1
15 08760045 CAP,END (SHAFT) 50-40"S CLUTCH 1
16 08760046 CAPSTAN, 50 IN SLIP BODY ASSY 1
17 08760055 CABLE .048-7X7-1' GAL ARCFT ST 1
18 12023300 SETSCREW, .250-20- .50-HXSO-SC 2
