4
Specifications
Model 360 ° panoramic camera
Signal System NTSC or PAL
Pick up device 1/3.2” Color CMOS QSXGA (5Mega Pixel : 2592x1944) image sensor
Synchronizing Internal
Scanning System 2:1 Interlace
S/N Ratio More than 51dB
Electronic Shutter x3; x2; x1; AUTO; 1/100; 1/120; 1/250
White Balance Auto
Diagonal 185°
Horizontal 185°
Angle of
view
Vertical 185°
Gamma Correct 0.45 / 1
RS485 PELCO D / 9600
Video Output 4 channels CVBS / HDMI / SDI
Lens Type Board lens 1.19 mm / F2.0
Format 1080p
Power Source 12 VDC jack ± 10% / 1A
Power Consumption 6.6 W (max)
Current 550 mA (max)
Operating
Temperature
-10°C ~ 50 °C (14°F ~ 122°F )
Storage Temperature -20°C ~ 70°C (-4°F ~ 158°F)
Dimensions (H x ø)
78.82 x 145 mm
78.82 x 190 mm
