In General Setup, denoted by the display box with scroll bar at the top of the screen (see
Section 4.0), there are several options to modify:
•
Turn channels ON/OFF
•
Set Low Alarm
•
Set High Alarm
•
Set scales for each channel
•
Set scales for graph display (This setting can be changed even after data has
been downloaded)
•
Set Alarm Delay
•
Set Units for Alarm Delay
Scrolling to the right will reveal that it is also possible to set the Graph Max and Min
settings for the Y-Axis of Temperature and RH. (These can be changed after download)
The Colours used for the lines on the graph can also be set at this time. (These can be
changed after download). The line width for the graph can also be changed. (These can
be adjusted after download)
For more detailed information on other sections of the task please refer to the main user
guide within the software section 4.0 Writing Tasks for EV Loggers.
5.0 Programming tasks to Loggers
When the task is finished, select ‘Program’ to send the task to the logger and to save it to the
task database. The logger is now ready for use.
5.1 After a task has been programmed
After a task has been programmed to a logger there are two possible outcomes.
1.
The logger is set for manual start
2.
The logger is set for an automatic start, with delay (EVt only if progammed) or
without delay (EV and EVG).
