2
SENSOR HEAD INSTALLATION
2.1
Caution: High Temperatures
Be careful when installing or removing the high temperature system.
Incidental contact with the process pipe may cause serious burns.
The sensor cover and fasteners may become extremely hot.
Always use appropriate gloves and clothing.
WARNING
Potential burn hazard. Always wear appropriate gloves when
installing or removing system from hot pipes.
2.2
Tools Required For Installation
Refer to the VF-100 Installation Manual for a list of tools required for
installation. Additional tools and supplies are listed below
Sensor Materials
Sensor Tools/Supplies
0.005” thi
ck polyimide sheet
9/32” socket or slotted screwdriver
adapter for use with torque wrench
Sensor alignment sheet
Torque wrench with 22 in-lb capacity
f
Alignment sheet attachment springs
2 ea ¼” x 20’ roll of 100% expanded
Value Seal Joint Sealant
8 sensors
Cover Materials
Tefzel
®
cable tie
Cover Assembly
Wire number tags
Preamplifier Assembly
Senso
r alignment sheet springs
Cover Fastener Kit
Table 1
Materials & Tools For Elevated Temperature Sensor Head Installation
21020-01 Rev 01
Page 2-2
