4 System memory
System
Memory
Memory
Channel
Configuration
DIMM 2
(Ch A,
Black)
DIMM 1
(Ch A,
Blue)
DIMM 4
(Ch B,
Black)
DIMM 3
(Ch B,
Blue)
DIMM 6
(Ch C,
Black)
DIMM 5
(Ch C,
Blue)
2GB
Dual
-
1GB
-
1GB
-
-
3GB
Triple
-
1GB
-
1GB
-
1GB
4GB
Dual
-
2GB
-
2GB
-
-
4GB
Triple
(unbalanced)
-
2GB
-
1GB
-
1GB
5GB
Triple
(unbalanced)
-
2GB
-
2GB
-
1GB
6GB
Triple
-
2GB
-
2GB
-
2GB
7GB
Triple
(unbalanced)
1GB
2GB
-
2GB
-
2GB
8GB
Triple
(unbalanced)
2GB
2GB
-
2GB
-
2GB
9GB
Triple
1GB
2GB
1GB
2GB
1GB
2GB
9GB
Triple
(unbalanced)
2GB
2GB
1GB
2GB
-
2GB
10GB
Triple
(unbalanced)
2GB
2GB
2GB
2GB
-
2GB
11GB
Triple
(unbalanced)
2GB
2GB
2GB
2GB
1GB
2GB
12GB
Triple
2GB
2GB
2GB
2GB
2GB
2GB
Possible Memory Configurations
