54
4.11 Invoking setup
The setup function can be invoked by pressing F2 when “Press to enter Setup”
message is prompted on the bottom of screen during POST.
During setup, all Fn function keys and power saving functions are disabled.
4.11.1 Main Menu
InsydeH20 Setup Utility
Main Advanced Security Boot Exit
System Time [12:00:00]
System Date [01/01/2010]
Processor Type Type,XXXGHZ
System Memory Speed XXXX MHz
Total Memory XXX MB
EC version
System BIOS Version: X.XX.XX
Intel ME Version
HDD Disk: XXXXXX
CD/DVD Rom: XXXXXX
Removable Device State: XXXXXX
Serial Number
UUID
Details see the
following
Help Information
F1 Help ↑↓ Select Item F5/F6
Change Values
F9 Setup Defaults
Esc Exit ←→ Select Screen Enter Select
4SubMenu
F10 Save and Exit
System Time and System Date
The hour is displayed with 24-hour format. The values set in these two fields take
effect immediately.
Processor Type
This field shows CPU type and speed.
