1 - 20 System Map: Right & Rear Views
Quick Start Guide
1
System Map: Right & Rear Views
Figure 1 - 11
Right & Rear Views
1. Microphone-In
Jack
2. Headphone-Out
Jack
3. USB 2.0 Port
4. Optical Device
Drive Bay (for CD/
DVD Device)
5. Security Lock Slot
6. Battery

Battery Information
Always completely dis-
charge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See
“Battery Information”
on page 3 - 11 for full in-
structions.
1
2
5
6
1 4 2 3
5 6
Model A
Model A
3
Model B
Model B
Model C
1 2 3
4
4
Model C
6
5
