Bottom Side View
1. Stereo
Speakers
Give high quality sound blaster with stereo system and Hi-Fi function supported.
2. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.
3. Battery
Pack
This notebook will be powered by the battery pack when the AC/DC adapter is disconnected.
1. Stereo
Speaker
2. Venilator
3. Battery
Pack
4. Battery
Release
Button
5. Battery
Lock/Unlock
Button
2
2
2
5
3
4
1
