4.4 Button VCR / ENTER
● VCR : Press the VCR (*L) button to enter VCR playback
mode. The user can use 4 arrow keys and 4 channel
keys(
▲,▼,◄,►，1/9，2/10，3/11,4/12) to select each channel
in the VCR mode. Press the VCR (*L) button again will return
to previous display mode.
● ENTER : In menu setup mode ,press the ENTER (**S) to
select the value.
4.5 Button M4-A
/ ▲
● M4-A: Press the M4-A (*L) button to enter PTZ controlling
function.Press the M4-B (*L) button again to exit PTZ
controllling function.
● M4-A: Press the M4-A (**S) button to display master QUAD.
● ▲: Press the ▲ (**S) to move cursor in menu setup.
4.6 Button M4-B
/ ▼
● M4-B: Press the M4-B (**S) button to switch channel for PTZ
in opening PTZ function.
● M4-A: Press the M4-A (**S) button to display slaver QUAD.
● ▼: Press the ▼ (**S) to move cursor in menu setup.
4.7 Button M8/
◄
● M8: Press the M8 (**S) button to switch 8 split display.
● ◄: Press the ◄ (**S) to move cursor or adjust the value in
menu setup.
4.8
Button M9/
►
● M9: Press the M9 (**S) button to switch 9 split display.
● ►: Press the ► (**S) to move cursor or adjust the value in
menu setup.
4.9 Button
1/9
/ FULL,
2/10
/ FULL,
3/11
/ FULL
…ect.
● 16 channel keys select camera to be displayed as full
screen.
4.10 PAL/NTSC System
System can be defined as NTSC or PAL standard with the
following method. The first method is power on with pressing
7/15 or 8/16 key and the second one is to define in the setup
menu.
