Carter-Hoffmann HL8-10-RW User Manual

Page 18

This list is not a complete list of spare parts. Contact Carter-Hoffmann technical service at
800-323-9793 if you do not see the part number you are looking for.

PARTS LIST—DRAWER WARMER

NOTE:

The technical content of this manual, includ-
ing any wiring diagrams, schematics, parts
breakdown illustrations and / or adjustment
procedures, is intended for use ONLY by
qualified technical personnel.

NOTE:

For warranty service, call Carter-Hoffmann di-
rect at 800-323-9793 for authorization, we will
dispatch the nearest authorized service agen-
cy.

Part Number Description

18612-0146

120v/450w Drawer Warmer Element

18601-1151 Pilot Light—Drawer Warmer

18600-0024 Thermostat—Drawer

Warmer 18608-0032

Knob-Drawer

Warmer

Part Number Description

17040-2214

Door gasket

18612-0315 120v, 1000w element (air)

18614-0291 Motor

18602-0160 Rocker

switch

18616-0023

Controller

18603-5018 Motor fan blade

18616-0224

24v output transformer

16006-0534 Glass door assembly

29038-4128

Glass door only

18302-0050 Door latch

18304-0030

Door hinges

18614-0314 Cooling Fan

18600-0046

High Limit

18608-0028 Controller Knob

18312-0352

Face Overlay

29037-9042 Black bezel housing

18605-5020

12/3 SO power cord

18606-0221 NEMA 5-20P angled plug

PARTS LIST—HOLDING CABINET
