5.6 Running a Program
The current program can be started from the home display by pressing RUN/HOLD. Or by
pressing page
 once, then scroll  once (twice for P10 and P25), then press up  or
down

5.7 To pause (hold) a program
Press RUN/HOLD
or
Press page
 until Program Status Reset appears
Press scroll
 until the cursor moves to Reset
Press up
 or down  to select Hold
RUN/HLD will be displayed
5.8 To stop and reset a program
Press and hold RUN/HOLD
or
Press page
 until Program Status Reset appears
Press scroll
 until the cursor moves to Reset
Press up
 or down  to select Reset
5.9 To run a different program (P10 and P25)
To select a program
Press page
 until Program Status Reset appears
Press scroll
 then up  or down  to select a program number
To run the program
Press RUN/HOLD
or
Press scroll
 until the cursor moves to Reset
Press up
 or down  to select Run
Run will be displayed
5.10 Program Status
While a program is running the home display shows 3 values:
Top: Measured temperature
Centre: Program setpoint (PSP)
Bottom: Power output percentage
To see more detail:
Press page
 once to go to the program status page. The top and centre values from the
home page remain on the display. The lower half of the screen now shows:
Current program number (P10 and P25 only)
Current segment number
Time remaining for that segment
Further presses of the scroll
 key while a program is running will reveal additional
information:
Status. This can be changed to Hold, Reset or Run by pressing up  or down .
