Program number
On P10 or P25 models press up
 or down  to select a new program number. The
display will show that new programs have only one segment.
Holdback Value
Press scroll
 until the display shows “Holdback Value”. If required: Press up  or down 
to set a value. This value will be used in any segment where a Holdback Type is set.
Ramp Units
These apply to Rate segments only. Press scroll
 until the display shows “Ramp Units”.
Press up
 or down  to select the ramp units of degrees per Hour, Min or Sec.
Number of program cycles
Press scroll
 until the display shows “Cycles”. Press up  or down  to select more than
one cycle.
Now create all the segments for your program, finishing with an End segment. When
parameters for each segment have been entered the display goes to the next segment
number.
Segment Type
Press scroll
 until the display shows “Segment Type”. Press up  or down  to select
Rate, Time, Dwell, Step, Wait, GoBack, Call or End.
Holdback Type
Press scroll
 until the display shows “Holdback Type”. If required, press up  or down 
to select Off, Low, High or Band.
Target Setpoint (Visible only for Rate, Time and Step segments)
Press scroll
 until the display shows “Target SP”. Press up  or down  to set a value.
Ramp Rate (Visible only for Rate segments)
Press scroll
 until the display shows “Ramp Rate”. Press up  or down  to set the
number of degrees per Ramp Unit as set above.
Duration (Visible only for Time and Dwell segments)
Press scroll
 until the display shows “Duration”. Press up  or down  to set a value.
Wait For (Visible only for Wait segments)
Press scroll
 until the display shows “Wait For”. Press up  or down  to select:
PrgIn1, PrgIn2, PrgIn1In2, PrgIn1orIn2, PVWaitIP.
GoBack to segment number (visible only for GoBack segments)
Press scroll
 until the display shows “GoBack Seg”. Press down  to select a segment
number to go back to.
GoBack Cycles (visible only for GoBack segments)
Press scroll
 until the display shows “GoBack Cycles”. Press up  or down  to set a
value.
Call Cycles (Visible only for call segments)
Press scroll
 until the display shows “Call Cycles”. Press up  or down  to set a value.
End Type (Visible only for End segments)
Press scroll
 until the display shows “End Type”. Press up  or down  to select Reset,
Dwell or SafeOp.
