LCD Display Information
The CalDigit VR2 LCD displays information in the following order:
System Profile - will display the status of 8 features
RAID status
Displays the current RAID status.
Serial number
Displays the CalDigit VR2 serial number.
Firmware version
Current CalDigit VR2 firmware version.
System temp
Displays the current system temperature.
Disk 1 temp
Displays temperature of the top hard drive.
Disk 2 temp
Displays temperature of the bottom hard drive.
Beeper status, LCD config status
Provides beep alarm status, provides LCD menu configuration status.
Access LED status, Auto rebuild status
Provides LED access status, provides auto rebuild status.
Create RAID - 3 different RAID levels can be set
Create RAID 0
Data is written onto two hard drives at a time for maximum speed.
Create RAID 1
Identical data is written onto two hard drives with maximum protection.
Create SPAN
Combine two hard drives into one volume, data will be accessed from the first
hard drive until full, then the second hard drive will be used.
Create JBOD
“Just a Bunch of Disks” Creates 2 independent volumes, one from the disk 1 and
the second from disk 2. This mode can also be used to read a single drive from a
RAID 1 mirror, however once used the RAID 1 mirror cannot be restored.
Clear RAID Info
Clears the RAID table information on the CalDigit VR2 and both drives.
1
2
LCD Menu Overview
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
2.1
2.2
2.3
2.4
2.5
