CalDigit VR User Manual

Page 8

2. Create RAID - 3 different RAID levels can be set
2.1 Create RAID 0

Data is written onto two hard drives at a time for

maximum speed.

2.2 Create RAID 1

Identical data is written onto two hard drives with

maximum protection.

2.3 Create SPAN

Combine two hard drives into one volume, data will be

accessed from the first hard drive until full, then the

second hard drive will be used.

3. MISC config - internal system set up
3.1 LCD power on / off

Turn the LCD display screen on or off.
3.2 Beeper on

Turn on the audible alarm.
3.3 Beeper off

Turn off the audible alarm.
3.4 Load default cfg.

Reset default settings.

For more information about LCD, please go to

http://www.caldigit.com/support.asp
