1.4. Disk brake installation
The Deville disc bolt pattern uses caliper mount for post mount 160 (PM160).
To assemble the disc brakes, follow this procedure:
1. Install the DH disc brake system, according to disc brake manufacturer's specifications.
2. Be sure to torque all fasteners and bolts to manufacturer's recommendations. Consult the instructions that came with your
disc brakes for proper installation procedures. It is recommended to install a NEW disc brake pads, to ensure proper alignment
and to minimize drag.
3. Route the disc brake hose (for hydraulic disc brakes) or brake cable housing (for mechanical disc brakes) from the caliper to the
inside of the lower leg and through the supplied disc brake hose guide.
4. Tighten the disc brake hose guide screw (M3 x 12) with a 2.5 mm-hex key wrench, and torque it to 1 N.m.
5. Test the brakes for proper operation on level ground before hitting the trails.
The disc brake caliper mounting bolts must have 10 mm of thread engagement with the fork.
In any case, the disc brake caliper mounting bolt tightening torque level must never exceed 10 N.m.
2.1 Air Spring
The sag measurement is the amount that your fork, rear shock, or both will compress when you are positioned for riding on your
bike, with all your riding apparel and gear. Adjusting air pressure until you achieve your target sag will help you to determine the
appropriate amount of air pressure for your fork or shock, or both.
To achieve the best performance from your BOS suspension product, the proper measuring and setting of sag is vital. As a starting
point, set sag for your fork or rear shock according to the following instructions:
Recreational use :
Weight (Kg/lbs) 55/120 60/132 65/143 70/154 75/165 80/176 85/187 95/210 105/132 110/242
Air pressure (psi) 45 55 60 70 75 85 90 100 105 115
Racing use :
Weight (Kg/lbs) 55/120 60/132 65/143 70/154 75/165 80/176 85/187 95/210 105/132 110/242
Air pressure (psi) 50 60 65 75 80 90 95 105 110 120
The Deville AM has an o-ring on the fork upper tube in order to measure the SAG position. You can experiment and vary your sag
percentage to better suit your riding style and overall feel.
2 . Settings
Caution :
Minimum air pressure : 45 psi
Maximum air pressure : 120 psi
Air Valve Cap
Air Valve
