Bos DEVILLE AM 2014 Manual startup - Manual

We thank you and congratulate you for choosing BOS product, designed and developed by
enthusiasts and handmade with care in France.
Please refer to the user manual available in the download section at www.bosmtb.com. It contains
the important safety, maintenance, and warranty information you need in order to safely install and
use your BOS suspension as well as the detailed set-up, tuning, and service information.
Air pressure
Whatever your weight, the air pressure should be between 45 and 125 psi.
NB : Pressions give on an indicative basis. You can adjust it ± 10 psi according to your use and your riding stile .
Recreational use
Weight (kg/lbs) 55/120 60/132 65/143 70/154 75/165 80/176 85/187 95/210 105/231 110/242
Pressure (psi) 45 55 60 70 75 85 90 100 105 115
Racing use
Weight (kg/lbs) 55/120 60/132 65/143 70/154 75/165 80/176 85/187 95/210 105/231 110/242
Pressure (psi) 50 60 65 75 80 90 95 105 110 120
Air chambers balance
Balance the pressure of the air chambers in each pressure adjustment to ensure optimum
performance. To do this, squeeze and slowly release your fork on the first 10 mm of travel a dozen
times.
Starting point adjustments : from the fully closed position
Rebound (A) :
Recreational use : 18 clicks
Racing use : 16 clicks
Compression (B) : 3 Positions
- Soft : comfort
- Intermediate : hydraulic and grip control
(adjustable intensity, refer to the user manual).
- Hard : Push pull efficiency
Quickstart
Assemblé à la main en France
Hard
