NOTE: Both models have 2 rams, a standard 2 HP motor (230/60/1PH), a standard
speed of 8 fpm, a 50” travel, and a shipping weight of 2450 pounds.
LOAD CAPACITY
The load capacity rating is stamped on a metal plate attached to the lift. This figure is a
net capacity rating for a lift furnished with the standard platform. The relief valve of the
pumping unit has been set to raise the weight, plus a small amount for overload. Where
gravity roll-sections, special tops, etc, are installed on the lift after leaving the plant,
deduct the weight of these from the load rating to obtain the net capacity. Lifts should
not be overloaded beyond the established capacity as damage and/or personal
injury may result.
UNBALANCED LOADING
The stabilization provided is basically for balanced loads. If special attachments extend
beyond the length and/or width dimensions of the platform, the end and/or side load
capacity is reduced 2% for each one-inch extension from the center.
PUMP PRESSURE
This lift incorporates a positive displacement pump machined to a high degree of
accuracy and specially adapted to requirements of higher-pressure ranges over that of
a standard pump. Therefore, standard factory models of the same manufacture cannot
replace it.
The pump can operate efficiently at intermittent pressures up to 3200 PSI and
continuous duty to 2500 PSI. The safety relief valve in the pump assembly is factory-
set to stay within the parameters of the pump and lift requirements.
Model Lifting
Cap.
(lbs)
Axle Load
Capacity
Over
Bridge End
(lbs)
Axle Load
Capacity
Opposite
Bridge End
(lbs)
Axle Load
Capacity
Over
Sides
(lbs)
Approx.
Std.
Power
Unit Dim
(Inches)
Standard
Platform
(Inches)
Base
frame
Size
(Inches)
Min.
Lowered
Height
(Inches)
CMD-30 3000 1500 1500 1500 Built-in 72 x 72 60 x 75 5 3/8
CMD-40 4000 2000 2000 2000 Built-in 72 x 72 60 x 75 5 3/8
SPECIFICATIONS
