Page 3: Step five – picture settings and adjustments

background image

If you wish to receive product updates, register your

Artograph product at www.artograph.com.

All information will remain confidential and solely for Artograph use.

Artograph provides free lifetime telephone

technical service support on the LED 500

TM

1. Grid Templates/Patterns (not covered in CD or printed manual)
a. The LED 500

has 19 composition grid templates/patterns built into the device to

simplify the process of art composition, alignment and scaling
b. Select “Grid” on the remote; press left or right arrows to
Select desired grid and grid color based on the projected surface
2. Auto Keystone (Pages 23, 51) – LED 500

auto adjusts to the right angle when

focused on an angled surface.
a. Select the key.S

p

/ key.S

q

on the remote for further keystone adjustment

3. Grayscale (Page 46) Color images can be adjusted to grayscale to aid in tracing and/or
to evaluate tonal values
a. In

“USB” mode, select “Q.Menu”

g

“Set Video”

g

using the arrow keys

on the remote, scroll down to

“Color”; adjust the color down to zero

b.

All other devices – select “Settings”

g

“Options” g using the arrow keys on

the remote, scroll down to

“Grayscale” and turn “on” or “off”

(OR)
c.

Alternate method – select “Settings”

g

“Picture”

g

“Color”; adjust color

down to zero

4. Rotating/Flipping Images (Page 35) The LED 500

allows you to rotate and flip

images to suit your artistic requirements
a.

USB Mode only – when previewing an image, use

i

arrow key to move to bottom

of image; use

g

arrow key to move right to ;

g

Ok as many times as necessary

to orient the image correctly.
b.

Flipping images (Page 51) – (Must exit from USB)

g

“Settings”

g

“Option”

g

“PJT Mode”

5. Enlarging Photos (Page 35) USB mode only; images can be enlarged up to 400%

a. i Arrow down to bottom bar on the image;

g

to the right until coming the the

magnifying glass symbol;

g

OK

g

blue button with four dots ;

repeat

g

symbol again to scroll up to 400% enlargement; use the arrow keys to

then move around the magnified image

6. Picture Wizzard II (Page 47) adjusts the settings of each input to desired picture quality

and standards

(Exit USB mode completely to access this feature)

a. Select

“Settings” on the remote; scroll down to “Picture Wizzard II” and follow

the on-screen instructions

7. Edge Enhancement (Page 48) increases line clarity to enhance tracing

a. Works in USB Mode only;

g

“Settings” on the remote;

g

v

g

“Set Video”

“OK”

g

v to get to

“Edge Enhancer”;

g

> arrow to obtain level

desired

g

“OK”

Note: The LED 500

has been designed to function with most input devices, but not all.

Step Five – Picture Settings and

Adjustments

(Pages 46-48)

#306-376 ©2014

www.artograph.com

Composición, escalamiento y

visualización de imágenes...

de manera sencilla

Guía de configuración rápida

Antes de usar el LED 500

Digital Art Projector

, lea atentamente las siguientes

instrucciones detalladas de configuración y uso, y el Manual del propietario adjunto

y/o el CD. Familiarizarse por completo con la infinidad de características que ofrece

este producto simplificará el proceso de composición y escalamiento de obras de

arte, lo que le permitirá pasar más tiempo en la creación de arte.

Gracias

Gracias por adquirir el LED 500

TM

Digital Art Projector. Esta guía le ayudará con

la configuración y uso de esta herramienta para artes gráficos.

Observará que cada instrucción/característica tiene un número entre corchetes detrás, que

identifica el número de página en el Manual del propietario, donde puede encontrar información

adicional sobre este paso. El CD* adjunto brinda estas mismas instrucciones en 27 idiomas.

Le recomendamos probar todas las características del LED 500

TM

Digital Art Projector para mejorar

su experiencia con el sistema. Es verdaderamente un producto diseñado para las mentes creativas.

Por preguntas sobre configuración y uso, o si tiene comentarios o sugerencias que desee brindar,

puede comunicarse con nuestra línea gratuita de Atención al cliente al 888-975-9555.

Atentamente, Artograph, Inc.

*Tenga en cuenta que el CD se refiere al LED 500

TM

como PB60A. Los “Extras opcionales”

descritos en el CD no necesariamente están disponibles de parte de Artograph, sino que pueden

estar disponibles de otras fuentes de productos electrónicos para consumidores.

Garantía

Los productos de Artograph

®

están garantizados contra defectos en materiales y mano de obra durante un período de un año a

partir de la fecha de venta al comprador original. Cualquier producto defectuoso será reparado o reemplazado por Artograph a

su elección, siempre y cuando el producto sea devuelto, con porte prepagado, a nuestra fábrica dentro del período de garantía.

El cliente deberá notificar puntualmente ya sea al vendedor original o a Artograph sobre cualquier reclamación de garantía

proporcionando información suficientemente específica que describa el problema y sus síntomas, junto con una copia del recibo

original de compra u otra prueba aceptable de compra. Todas las devoluciones aprobadas recibirán un número de autorización de

devolución. Todos los productos recibidos sin un número de autorización serán devueltos. Los equipos reparados o reemplazados

bajo esta garantía serán devueltos al cliente, previo pago del porte o franqueo. El período de garantía para los productos reparados

o reemplazados tendrá la misma duración que la garantía original. Esta garantía no cubre la reparación de daños en el producto

o en los componentes del producto ni su mal funcionamiento causado por (i) uso inadecuado, negligencia, cortes eléctricos o

sobretensiones, rayos, incendios, inundaciones o accidentes, (ii) el uso de productos o servicios suministrados por terceros, o (iii)

incumplimiento de las instrucciones de instalación, operación o mantenimiento.
LAS GARANTÍAS EXPRESAS CONTENIDAS EN EL PRESENTE DOCUMENTO SE BRINDAN EN LUGAR DE CUALQUIER

Y TODA OTRA GARANTÍA EXPRESA O IMPLÍCITA, INCLUIDAS ENTRE OTRAS, LAS GARANTÍAS IMPLÍCITAS DE

COMERCIABILIDAD, APTITUD PARA UN PROPÓSITO PARTICULAR Y DE NO CONTRAVENCIÓN, CADA UNA DE LAS

CUALES ES RECHAZADA POR EL VENDEDOR Y SE ENCUENTRAN EXCLUIDAS. AUNQUE NO HAY GARANTÍAS QUE SE

EXTIENDAN MÁS ALLÁ DE LA DESCRIPCIÓN DE LA PRESENTE GARANTÍA, LAS LEYES LOCALES DEL CLIENTE PUEDEN

ESTIPULAR LO CONTRARIO. EL VENDEDOR NO SERÁ RESPONSABLE POR DAÑOS, INCLUIDOS DAÑOS ESPECIALES,

INCIDENTALES O CONSECUENTES, INTERRUPCIÓN DE ACTIVIDADES COMERCIALES QUE SE PRODUZCAN POR O EN

RELACIÓN CON EL DESEMPEÑO DE LOS PRODUCTOS O SU USO POR PARTE DEL CLIENTE.
