• Specifications
Operational Versions
TLS-6A: Pump down; 3 ft. differential
TLS-6B: Pump up; 3 ft. differential
TLS-8A: Pump down; 12 ft. differential
TLS-8B: Pump up; 12 ft. differential
TLS-8AK: Pump down; high temp.
TLS-8BK: Pump up; high temp.
Control range: ................. (TLS-6) ...... 8 to 39 in. (270-1000 mm)
(TLS-8) ...... 12 to 157 in. (330-4000 mm)
Minimum SG: ................. (TLS-6) 0.7
(TLS-8) 0.9
Output contact rating: ..... (SPST): 50 VA; 300 V, 0.5 A AC (max.)
(resistive)
Material
Cable: .......................... PVC
Float: ........................... ABS resin
Rope: ........................... PE
Weight: ........................ painted cast iron
Pressure rating: ............... 2 bar
Operating temperature: .. (TLS-6; TLS-8) -10°C to 50°C
(TLS-( )K) -10°C to 70°C
Cable length: .................. 6 m
Float driver: .................... (TLS-6) ...... 70 x 107 mm
(TLS-8) ...... 83 x 165 mm
