Outputs
The DCR-WEB contains 2 relays which are capable of handling a 5 A load.
These relays have programmable BEGIN and END points as well as TYPE of
operation. The relays can also be jumpered NO (default) or NC. *see drawing on
earlier page of this manual.
MODE
DESCRIPTION PARAMETERS
EXPLANATION
BEGRLY 1
Begin Trip 1
Units = inches
Sets the begin point
Default = 24
of Trip 1.
• Straight line from inlet of press to reel or straightener exit point.
• Distance from transducer to material that is taut or no loop - condition that could
cause damage.
ENDRLY 1
End Trip 1
Units = inches
Sets the endpoint
Default = 36
of Trip 1.
TYPE 1
Trip 1 Type
Range = 0 - 7
Selects the type of
Default = 0
function Trip 1 will
See Trip Type Explanation for details.
perform.
BEGRLY2
Begin Trip 2
Units = inches
Sets the begin point
Default = 40
of Trip 2.
ENDRLY 2
End Trip 2
Units = inches
Sets the end point of
Default = 48
of Trip 2.
TYPE 2
Trip 2 Type
Range = 0 - 7
Selects the type of function
Default = 0
Trip 2 will perform.
See Trip Type Explanation for details.
