SPECIFICATIONS

UNIT SIZE-SERIES

024-A

030-A

036-A

042-A

Operating Weight (Lb)

291

ELECTRICAL

Unit Volts—Hertz—Phase

208/230—60—1

Operating Voltage Range*

187–253

Compressor—

Rated Load Amps

13.5

14.7

15.4

18.6

Locked Rotor Amps

61.0

72.5

83.0

105.0

Condenser Fan Motor—Full Load Amps

0.75

1.10

Minimum Unit Ampacity for Wire Sizing

TBD

Minimum Wire Size (60°C Copper) (AWG)†

TBD

Minimum Wire Size (75°C Copper) (AWG)†

TBD

Maximum Wire Length (60°C) (Ft)‡

TBD

Maximum Wire Length (75°C) (Ft)‡

TBD

Maximum Branch Circuit Fuse Size**

TBD

COMPRESSOR AND REFRIGERANT

Compressor—

Manufacturer

Copeland

Type

Scroll

Refrigerant—

Type

R-410A

Amount (Lb)††

9.88

10.25

10.50

OUTDOOR COIL & FAN

Coil Face Area (Sq Ft)

18.25

Fins per In.—Rows—Circuits

20—2—4

Fan Motor HP and RPM

1/8 and 825

1/5 and 825

Rated Airflow (CFM)

2400

2800

OPTIONAL EQUIPMENT

Support Feet—4 In. (4)

KSASF0101AAA

Coastal Filter

KAACF0201MED

Time-Delay Relay

KAATD0101TDR

Cycle Protector—5-Minute Time Delay

KSACY0101AAA

Start Assist—Capacitor/Relay Type

KSAHS1501AAA

TXV (Hard Shutoff)

KSATX0201HSZ

KSATX0301HSZ

Filter Drier (Suction Line)

KH45LG140 (RCD)

KH45LG141 (RCD)

Evaporator Freeze Thermostat‡‡

KAAFT0101AAA

Liquid-Line Solenoid Valve (LSV)

KAALS0201LLS

Winter Start Control

KAAWS0101AAA

Low-Ambient Pressure Switch

KSALA0301410

Low-Ambient Controller

P251-0083 (RCD)

MotorMaster® Control***

32LT660004 (RCD)

Ball Bearing Fan Motor

HC38GE230

Thermostat—Auto Changeover, Non-Programmable,
°F/°C, 1-Stage Heat, 1-Stage Cool

TSTATBHNAC01-A

Thermostat—Auto Changeover, 7-Day Programmable,
°F/°C, 1-Stage Heat, 1-Stage Cool

TSTATBHPAC01-A

Thermidistat™ Control—Programmable Thermostat
with Humidity Control

TSTATBHPRH01-A

Thermostat—Manual Changeover, Non-Programmable,
°F, 1-Stage Heat, 1-Stage Cool

HH07AT212

Outdoor Air Temperature Sensor

TSTATXXSEN01

Backplate for Non-Programmable Thermostat

TSTATXXNBP01

Backplate for Programmable Thermostat

TSTATXXPBP01

Thermostat Conversion Kit (4 to 5 Wire)—10 Pack

TSTATXXCNV10

* Permissible limits of the voltage range at which unit will operate satisfactorily. Operation outside these limits may result in unit failure.
† If other than uncoated (non-plated), 60° or 75°C (140° or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for larger than 10 AWG) is used,

consult applicable tables of the NEC (ANSI/NFPA 70).
If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70). The ampacity of nonmetallic-sheathed cable (NM), trade name
ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-30.

‡ Length shown is as measured 1 way along the wire path between the unit and the service panel for a voltage drop not to exceed 2 percent.
** Time-delay fuse or circuit breaker.
†† The factory refrigerant charge is for 15 ft of interconnecting tubing. For tubing lengths other 15 ft, refer to the Long-Line Application Guideline and Service Manual for

Residential Split-System Air Conditioners and Heat Pumps using R-410A.

‡‡ Use with low-ambient pressure switch.
*** Fan motor with ball bearings required.
TBD—To Be Determined
NOTE: Copper wire must be used from service disconnect to unit. All motors/compressors contain internal overload protection.
