L I G H T I N G E L L I P S O I D A L
PHOENIX CDM ELLIPSOIDAL
Housing: Die-cast aluminum construction
Yoke:
dog tilt handles, two mounting positions,
Indexed tilt angle markings.
Alzak aluminium ellipsoidal design
Lenses: Color coded crown glass (white
coating. Molded front lens made out of
polymeric plastic for 5 and 10 degree units
only.
Socket: 5kV Pulse rated Socket. Tool free re-lamping.
Ballast: Electronic Ballast 39, 70 & 150 w -Multi Voltage
Cable:
Shutters: Four .037” stainless steel, fully
adjustable and lockable. Constructed with
oversized heat resistant handles.
Included Accessories
6-CFB Black Color Frame, 6.25”x6.25”
510 Malleable Iron Pipe Clamp
SC-36-BK 36” Black Safety Cable with
Spring Clamp
Additional Accessories
10-CFB Black Color Frame, 12”x12”
included with PHX-10 and C10)
12-CFB Black Color Frame, 14”x14”
included with PHX-5 and C5
510-HD Heavy Duty Malleable Iron Pipe
Clamp
4.5-DN 6.25”x6.25” Donut, Black with
2-1/2” Hole
10-DN 12”x12” Donut, Black
12-DN 14”x14” Donut, Black
4.5-SN 6.25”x6.25” Snoot, Black
10-SN 12’x12” Snoot, Black
12-SN-BK 14”x14” Snoot, Black
PHX-PH Phoenix Steel Pattern Holder, “B”
Size
PHX-GPH Phoenix Glass Pattern Holder, “B”
Size
PDII Phoenix Drop-In Iris
Lighting
BRINGING IMAGINATION TO LIGHT
Lighting
BRINGING IMAGINATION TO LIGHT
57 Alexander St., Yonkers, NY 10701 Tel: 914-476-7987 Visit our website at www.altmanlighting.com
© 2012 Altman Stage Lighting, Inc.
Conversion Factors
39 Watt Lamp = f.c. x .24
70 Watt Lamp = f.c. x .48
Lux: = f.c. x .0929
Watts Efficiency
Lamp
Type
Color
Temp
(°K)
Color
Rendering
Index
Rated
Life
(Hours)
Rated
Lumens
39
70
70
150
150
150
CDM 35/T6/830
CDM 70/T6/830
CDM 70/T6/942
CDM 150/T6/830
CDM 150/T6/942
CDM SA150/T6/942
3000
3000
4000
3000
4000
4200
12,000
12,000
12,000
12,000
6,000
5,000
3,400
6,600
6,600
14,000
12,700
12,900
Burn
Position
Any
Any
Any
Any
Any
Any
81
82
92
85
95
96
>87 LPW
>92 LPW
>92 LPW
>93 LPW
>85 LPW
>86 LPW
L A M P D A T A
