Allen & Heath 3

XB-10 User Guide

CONTENTS

Thank you for purchasing your Allen & Heath XB-10 mixer. To ensure

that you get the maximum benefit from the unit please spare a few

minutes familiarizing yourself with the controls and setup procedures

outlined in this user guide. For further information please refer to the

additional information available on our web site, or contact our technical

support team.

http://www.allen-heath.com

http://www.allen-heath.com/xb

Warranty ..............................................

4

Packed Items ........................................

5

Safety Instructions ..............................

6

Panel Drawings ....................................

8

Introduction to XB-10 .......................

9

Specifications .......................................

11

Dimensions ..........................................

13

Block Diagram .....................................

14

Mono Input Channel ..........................

15

TELCO Channel .................................

18

Stereo Input Channels .......................

21

Outputs .................................................

23

Output Selection ................................

24

Master Section ....................................

25

Remote Interface Connector ..........

27

Connecting to a Computer ..............

29

Application Diagram - Self Op.........

30

Application Diagram - Studio...........

31

Application tip : VOIP caller ............

32

Wiring notes ........................................

33

Product Support .................................

34
