iDR-4 User Guide 47
Template for Allen & Heath iDR-4 Front Panel Key Label
File: iDR-4_label.dot for Microsoft ® Word
Each label is a table. You can format it in the usual way.
Edit the text to identify the key and LED functions (maximum of three lines per cell, each with eight characters).
Overall size of each label is 178.5 x 12.5 mm.
Adhere the labels into the iDR-4 front face plate slots provided.
1 2 3 4
5 6 7 8
