4. Administrating the Device
AirLive OD-2025HD
/OD-2025PHD User’s Manual
63
z
SAMBA Login name:
Type the user name for the SAMBA server.
z
SAMBA Login Password:
Type the password for the SAMBA server.
z
SAMBA Path:
Set working directory path of SAMBA server.
4.10 Event Schedule: Configure the Event Schedule
4.12.1 Setting
This menu is used to specify the schedule of Event or Schedule Trigger and activate the
some actions provided by this device. Where the Schedule Trigger will be activated by
user-define interval without event happened.
z
Name:
Name of the Event or Schedule.
