4. Web-Based Management
AirLive Ether-GSH2404W User’s Manual
29
„ Click Apply to apply the configuration
„ Or, click Refresh to reset the configuration before applying
QoS VLAN Tag Priority Mapping interface
„ Click DSCP Mapping to enter TOS priority configuration interface
¾ DSCP [0- 63]: the system provides 0~63 TOS priority level. When the IP
packet is received, the system will check the TOS level value in the IP packet
that has received. For example: user set the TOS level 25 is high. The port 1
is following the TOS priority policy. When the packet received by port 1, the
system will check the TOS value of the received IP packet. If the TOS value of
received IP packet is 25(priority = high), and then the packet priority will have
