4. Web-Based Management
AirLive Ether-GSH2404W User’s Manual
18
4.5.1 VLAN Port Setting
Click VLAN Port Setting to bring up the configuration interface for adjusting the
VID Setting
„ PVID: Enter the Port VLAN ID
„ Awareness:
¾ Enable: Transmit to the PVID group that the same with the packets’ VID.
¾ Disable: Transmit to the PVID group that the same with the incoming port’s
PVID.
„ Frame Type:
¾ Tag: Only allow tagged frame pass the port.
¾ All: Allow all type of frames pass through.
„ Click Apply to apply the configuration
„ Or, click Refresh to reset the configuration before applying
