AirLive Ether-FSH2402NT User’s Manual
12
Blinking : When the LED is blinking, the port is transmitting or
receiving data on the 10/100Mbps Ethernet network.
Off : No link.
9
100Mbps
On : When the LED lights on, the respective port is connected to
a 100Mbps Ethernet network.
Off : The respective port is connected to a 10Mbps Ethernet
network, or no link
Port 25 & Port 26 Status LEDs
9
LINK/ACT
On : When the LED lights on, the respective port is connected to
a 10/100/1000Mbps Ethernet network.
Blinking : When the LED is blinking, the respective port is
transferring or receiving data on a 10/100/1000Mbps
Ethernet network.
Off : No link.
9
1000Mbps
On : When the LED lights on, the respective port is connected to
a Gigabit Ethernet network.
Off : The respective port is connected to a 10/100Mbps Ethernet
network, or no link.
9
100Mbps
On : When the LED lights on, the respective port is connected to
a 100Mbps Fast Ethernet network.
Off : The respective port is connected to a 10Mbps or Gigabit
Ethernet network, otherwise, no link.
