AirLive Ether-FSH2402NT User’s Manual

9

60 Hz. The power switch is located at the rear of the unit adjacent
to the AC power connector and the system fan. The switch’s
power supply will adjust to the local power source automatically
and may be turned on without having any or all LAN segment
cables connected.







I

D E N T I F Y I N G

E

X T E R N A L

C

O M P O N E N T S

This chapter identifies all the major external components of the
Switch. Both the front and rear panels are shown below, with a
description of each panel features.

Front Panel

Figure 4. The front panel of the Switch
