9. Event
AirLive DM-720 User’s Manual 38
9
9.
Event
Click the Event to display the sub-menus including Event Server, Event List, motion
Detection, Tampering Detection and Schedule.
9.1 Event Server
1. Event Server
Click “Add” to create an event server; then the setting page pops up. Name it; select your
network type put on the storage location. This is optional to create the password for
certain group to use it. Then click the “Test” button to see if it works. It will show the
information on the pop-up window to see your setting if it has been made successfully.
There are 3 types of event transmission offered to select. There is a range 0~7 seconds
can be selected individually for pre-event and post-event. There are 3 suffix options for
naming image file by Name, Date Time and Sequential Number.
