Introduction
ECU Bridge belongs to the last generation of AIM loggers for car/bike installations.
There are two available versions of ECU Bridge:
• K line/CAN version – with OBDII connector – for an easy and quick
Plug&Play connection to the vehicle OBDII plug (suggested for stock ECUs).
• RS232/CAN version – with free cables – for a straight ECU connection
through the serial/CAN communication protocol (suggested for both stock
and after market ECUs). Supported ECUs database is constantly updated.
Refer to ECU connections” for
further information.
ECU Bridge samples but does not record data out coming from the vehicle ECU; it can
show them if connected to an high technology AIM display like MyChron3 Dash, TGDash
and Formula Steering Wheel or to SmartyCam, the AIM on board camera the only one
with data overlay.
ECU Bridge manages 3 different communication protocols:
• K
Line;
• CAN
Line;
• Serial RS232 line.
Technical Characteristics:
• ECU
interface;
• CAN protocol for external expansion modules;
• USB port for programming
• 8/18 V external power.
