ASSEMBLING YOUR DRIVE ENCLOSURE

8. Insert the mounting tabs on the free end of the front panel into the

second side rail, and hook the side rail onto the front of the enclosure.

9. Finish the assembly by pressing the rail into the six rectangular mounting

holes in the side of the enclosure.

IMPORTANT NOTE: IF YOU ARE USING WINDOWS 98 OR 98 SE, DO NOT
CONNECT THE DRIVE ENCLOSURE TO YOUR COMPUTER UNTIL DRIVER
INSTALLATION IS COMPLETED.

10. Plug the square-shaped connector of the USB cable into the USB port on

the rear panel of the Drive Enclosure. (If you want to use the FireWire
interface, plug either end of the FireWire cable into the FireWire port on
the back of the Drive Enclosure.)
