Assembling your drive enclosure – Belkin F5U210 User Manual
Page 7
5
ASSEMBLING YOUR DRIVE ENCLOSURE
6. Hook the first side rail around front edge of the enclosure, and press
the rail into the six rectangular-shaped mounting holes on the side.
7. If you are installing a hard disk, it is necessary to install the front panel.
Insert the tabs on one side of the front panel into the mounting holes in
the installed side rail.
