STUMP GRINDER 4
Section
assemBlY
2
1. Remove machine from shipping crate.
2. loosen the two handle knobs and bolts attaching the
upper handle bar.
3. Rotate the upper handle bar back to align with the
lower handle bar support bracket.
4. Retighten the handle bar bolts with the handle knobs.
Refer to figure below.
2.1 assemBle uPPer HanDle Bar 2.2 aDD moTor oIl
2.3 FIll THe Fuel TanK
warnInG
Check the oil level and, if needed, fill the engine crankcase
with the type and amount of oil specified in the engine
owner’s manual.
use only those types of fuels that are recommended in
your engine owner’s manual.
To add fuel:
1. Stop engine, wait for all parts to stop moving and
disconnect spark plug wire. Remove key from key
switch. allow the engine and muffler to cool for at least
three minutes.
2. Clean area around fuel fill cap and remove cap.
3. using a clean funnel, fill fuel tank to 1/2” below bottom
of filler neck to provide space for any fuel expansion.
Install fuel fill cap securely and wipe up any spilled
gasoline.
gasoline and diesel fuels are highly
flammable and their vapors are explosive.
To prevent personal injury or property
damage:
Store fuel only in approved containers,
in well ventilated, unoccupied buildings,
away from sparks or flames. A container
with a capacity of 2 gallons or less with a pouring
spout is recommended. Do not fill the fuel tank while
the engine is hot or running, since spilled fuel could
ignite if it comes in contact with hot parts or sparks
from ignition. do not start the engine near spilled fuel.
Never use fuel as a cleaning agent. do NoT MIx oIl
WITh FuEl.
Loosen these
knobs to adjust
handle bar
