12 INCH CHIPPER
19
SERVICE & MAINTENANCE
BEFORE INSpECTINg OR SERvICINg ANY pART OF ThIS MAChINE, ShuT OFF pOwER SOuRCE, REMOvE kEY,
DISCONNECT ThE BATTERY CABLES AND MAkE SuRE ALL MOvINg pARTS hAvE COME TO A COMpLETE STOp.
WarninG
FEED ROLLER BEARINg
ROTOR ShAFT
BEARINgS
(BEhIND ROTOR
ShEAvE)
gREASE zERk
FEED ROLLER BEARINg
DRIvE ShAFT BEARINgS
RAISE ROTOR
COvER TO ACCESS
ThIS BEARINg
.10.oz
.18.oz
.10.oz
.10.oz
.10.oz
