5 INCH CHIPPER iv
TaBle oF conTenTs
saFeTY ................................................................................................................ 1
1.1 SAFETy AlERT SyMBOl .....................................................................................1
1.2 EMISSION INFORMATION ....................................................................................1
1.3 BEFORE OPERATINg ...........................................................................................1
1.4 OPERATION SAFETy ...........................................................................................2
1.5 BATTERy SAFETy ................................................................................................3
1.6 MAINTENANCE/STORAgE SAFETy ....................................................................3
1.7 TOWINg SAFETy ..................................................................................................3
1.8 SAFETy DECAlS ..................................................................................................4
1.9 SAFETy DECAl lOCATIONS ...............................................................................5
assemBlY ........................................................................................................... 6
2.1 ATTACH TRAIlER WHEElS ................................................................................6
2.2 ATTACH TRAIlER HITCH ......................................................................................6
2.3 ATTACH CHIPPER CHuTE ...................................................................................6
2.4 ATTACH DISCHARgE TuBE .................................................................................7
2.5 INSTAll BATTERy ................................................................................................8
2.6 CHECk/ADD MOTOR OIl .....................................................................................8
2.7 FIll THE FuEl TANk ............................................................................................8
FeaTures & conTrols ................................................................................... 9
operaTion ....................................................................................................... 10
4.1 STARTINg ENgINE .............................................................................................10
4.2 STOPPINg ENgINE ...........................................................................................10
4.3 OPERATINg THE CHIPPER ...............................................................................10
service & mainTenance .............................................................................. 12
5.1 MAINTENANCE SCHEDulE...............................................................................12
5.2 CHIPPER BlADE MAINTENANCE .....................................................................13
5.3 REMOVINg THE BlADES ..................................................................................13
5.4 SHARPENINg THE BlADES ..............................................................................14
5.5 SETTINg BlADE ClEARANCE ..........................................................................14
5.6 ADJuSTINg/REPlACINg DRIVE BElT ..............................................................14
5.7 REPlACINg ROTOR BEARINgS .......................................................................15
5.8 ClEARINg A PluggED ROTOR .......................................................................16
5.9 luBRICATION .....................................................................................................16
TrouBleshooTinG ........................................................................................ 17
speciFicaTions ............................................................................................... 18
BOlT TORQuE ...........................................................................................................19
opTions ............................................................................................................ 20
DescripTion paGe
