Echo CH5653 Owners Manual v.1 - Manual (Page 22)

5 INCH CHIPPER 18
TROUBLESHOOTING
section
speciFicaTions
7
Excessive vibration while
running.
Drive system vibration.
Check drive belts and pulleys for bad or worn areas. Check for
dull chipper blades or shredder knives.
Rotor out of balance.
Inspect rotor for broken or missing chipper blades and shredder
knives; replace if needed. Check rotor to see if it wobbles. Check
to see if rotor is assembled correctly.
Chipper blade to anvil
clearance is incorrect.
Set chipper blade/anvil clearance to recommended distance (1/16”
to 1/8”).
rotor will not turn.
Drive belt too loose or broken. replace belt or spring.
Obstructed discharge. use branch or similar object to clear discharge.
Plugged rotor. Clear rotor. Feed material more evenly.
Cannot engage clutch.
Improper belt installation; belt
not under belt guide.
Install belt properly; install belt under belt guide.
Improper belt tension. Adjust belt tension. Replace belt or spring if needed.
Excessive belt wear.
Not using correct belt.
Contact your nearest authorized dealer to order the correct belt for
your chipper/shredder.
Pulley(s) damaged or worn. Replace pulley(s).
Pulley(s) not in alignment. Align pulley(s) with straight edge.
Belt(s) tension too loose. replace belt or spring.
Trailer sways during
towing.
Tire air pressure not correct Check tire sidewall for inflation limits.
ch5653
DescripTion english metric
OVERAll SIZE 73" x 52" x 87" 185.4 x 132.1 x 221.0 cm
OVERAll WEIgHT 820 lbs 372.7 kg
MAX CHIPPER CAPACITy 5" 12.7cm
CHIPPER BlADES 4 reversible
CHIPPINg ANVIl 5.63" X 4.00" X 0.375" 14.3 cm x 10.2 cm x 0.95 cm
DISC SPEED 1825 rPM
DISC SIZE 20" x 1.25" 50.8 cm x 3.2 cm
DISC WEIgHT 140 lbs. 63.6 kg
DISCHARgE TuBE SIZE 6" 15.25 cm
DRIVE TyPE BElT
DRIVE BElT SIZE 2rbP67
TIRE SIZE 5.30-12
ENgINE 653cc Subaru EH65
FuEl TANk CAPACITy 6.6 gal. 25 liters
