13
installing the Seat and attachments
leg extension
The Leg Extension is used when doing leg extension and leg curl exercises. To attach the Leg Extension, pull down
on the pop-pin under the seat and insert the leg extension into the mounting bracket. Slide the Leg Extension to the
desired position and screw the pop-pin tightly into place. Then attach the hooks on the ends of the Squat Pulley
cables to the snaphook on the Leg Extension.
Leg Extension
Assembly
Seat
Pop-pin
