Wireless HDMI Receiver:
1. Power Button with LED Indicator:
- Lights green when powered on
- Lights red when in Standby Mode
2. Source Button
3. Video Status LED
- Off when in Standby Mode
- Blinks at initial boot up / warm up (15~20 seconds)
- When in wireless linked mode:
a. Blinks quickly when there’s no input from a
selected source
b. Blinks slowly when the video format is not
recognized
c. Static green when the video format is
recognized
4. Wireless Status LED
- Off when in Standby Mode
- Blinks at initial boot up / warm up
- Blinks when searching for available channels
- Static green when in wireless linked mode
5. Mini USB Power Jack
6. HDMI Output
Top View Back View
5
1
2
3
4
6 7
