Installation of video extender – IOGear GVE120 Manual User Manual
Page 17
Category 5, 5e, or 6 twisted pair cable
Power Adapter’s Cable
Remote Monitor’s VGA cable
Remote Unite
Installation of Video Extender
15
8.Plug the remote monitor’s VGA cable into the Remote Unit’s Monitor port.
9.Plug the second power adapter (supplied with this package) into a remote surge protector power strip; plug
the adapter’s power cable into the Remote Unit’s Power Port.
10.Power On the computer and monitors.
Note: Refer to the
Cable Length
table in the Technical Details section on page ___ for typical resolution/
refresh rate/distance ratios.
