Pictorial introduction – remote unit (gve120r) – IOGear GVE120 Manual User Manual
Page 13
11
Remote I/O
The Category 5, 5e, or 6 twisted pair cable that connects to the Local Unit plugs into this connector.
Power Port (AC 9V)
The power supply cable plugs into this connector.
Power Indicator Light
Lights to indicate that the unit is receiving power.
Monitor Port
The remote monitor’s VGA cable plugs into this connector.
Pictorial Introduction – Remote Unit (GVE120R)
