Installation of video extender – IOGear GVE120 Manual User Manual
Page 14
Male end VGA extension Cable
Female end VGA extension Cable
12
Warning!
Make absolutely sure that a protective ground wire with no potential difference is established between the AC
sources for the Local and Remote units. Unequal grounding potential between the Local and Remote units
will result in damage to the units and connected devices.
Refer to the pictorial introduction as you follow the step-by-step directions below:
Make sure that the computer and monitors you are using for the installation are powered Off.
Plug the male end of the VGA extension cable into the computer’s video output port; plug the female end of
the cable into the Local Unit’s PC (computer) port.
1.
2.
Local Unite
Installation of Video Extender
