IOGear GCS1782G User Manual
Page 11
11
No.
Component
Description
1
USB Console Ports
USB Keyboard and mouse connections*
2
Console Port Section
Connections for your monitor, mic, and speakers
3
CPU Port Section
Connections for the cables that link the switch to your computers. Each
CPU port is comprised of a microphone jack, speaker jack, USB type B
socket and a DVI connector
4
Power Jack
Power adapter connection
5
USB Peripheral Port
Connection for USB 2.0 peripherals ( printers, scanners, etc)
