Specifications
Function
GCS1722
GCS1724
Computer Connections
2
4
Port Selection
Front panel Pushbuttons; Hotkey, USB Mouse
Connectors
Console Ports
Keyboard
1 x USB Type A Female (Black)
1 x 6-pin Mini-DIN Female (Purple)
Video
1 x HDB-15 Female (Blue)
Mouse
1 x USB Type A Female (Black)
1 x 6-pin Mini-DIN Female (Green)
KVM Ports
2 x SPHD-18 Female (Yellow)
4 x SPHD-18 Female (Yellow)
Power (Optional)
1 x DC Jack
1 x DC Jack
Switches
Selected
2 x Pushbutton
4 x Pushbutton
LEDs
On Line
2 (Orange)
4 (Orange)
Selected
2 (Green)
4 (Green)
Emulation
Keyboard / Mouse
USB
Video
2048 x 1536 @ 60Hz; DDC 2B
Scan Interval
3, 5, 10, 20 secs. (5 secs. default)
Power Consumption
DC 5V, 1.1W
DC 5V, 1.2W
Environment
Operating Temp.
0 ~ 50°C
Storage Temp.
-20 ~ 60°C
Humidity
0 ~ 80% RH, Non-condensing
Physical Properties
Housing
Metal
Weight
0.54 kg
0.77 kg
Dimensions (L x W x H)
14.00 x 8.70 x 5.50 cm
21.00 x 8.70 x 5.50 cm
