HSM Summary Table
After invoking HSM (see page 15), key in one of the following keys to perform the corresponding func-
tion:
- 21 -
Hotkey Setting Mode (HSM)
Key Function
[H] Toggles between the default ([Num Lock] [-]) and
alternate ([Ctrl] [F12]) HSM invocation keys.
[T] Toggles between the default ([Scroll Lock] [Scroll
Lock]) and alternate ([Ctrl] [Ctrl]) Port Switching
keys.
[F2] Enables Mac keyboard emulation.
[F3] Enables Sun keyboard emulation.
[F10] Automatically detects and sets the keyboard
operating platform.
[F4] Prints the switch’s current settings via a text editor
or word processor.
[F5] Performs a reset on all USB devices.
[F6] [nn] [Enter] Sets the keyboard language.
Key Function
[B] Note: nn is a two-digit number that represents
one of the following keyboard language code: US
English: 33; French: 08; Japanese: 15.
[X] [Enter] Enables/Disables the buzzer.
[R] [Enter] Enables/Disables the port switching keys.
[u] [p] [g] [r] [a]
[d] [e] [Enter] Resets the hotkey settings to their default status.
[D] Invokes Firmware Upgrade Mode.
[N] Invokes Video DynaSync™, ATEN’s exclusive
technology that eliminates boot-up display
problems and optimizes resolution when switching
between ports.
[M] Enables/Disables keyboard emulation.
[W] Enables/Disables mouse emulation.
[F1] Enables/Disables mouse port-switching.
Resets keyboard and mouse under operating
systems that do not support USB 2.0.
