OverviewOverview
Overview Overview
4 4
Front View:
1 Selected LEDs
These LEDs indicate the currently selected port.
2 Auto Scan LED
The Auto Scan LED flashes when Auto Scan Mode is in
effect.
3 Port Selection Switch
The Port Selection Switch is located on the front panel,
just opposite the Select Arrow on the front panel. Press
this push button to cycle among the connected com-
puters. The Selected LED on the front panel lights to indi-
cate which port is selected.
4. On-Line LEDs
These LEDs indicate that a computer is properly con-
nected to the switch, powered on and operational.
5. Auto Scan Switch
This push button toggles Auto Scan Mode for the
MiniView
TM : USB.
