SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL
3-10 – JLG Lift – 3120685
EMERG. STOP
PUSH DOWN
STEER
LEFT
FWD
REV
DRIVE DRIVE
PLATFORM SHALL NOT BE
OCCUPIED WHILE USING
THIS CONTROL. KEEP
CLEAR OF MACHINE WHILE
DRIVING.
STEER
RIGHT
ON
P
O
W
E
R
CAUTION
PRIOR TO JULY 1992
OCTOBER 1992 TO MARCH 1994 MARCH 1994 TO PRESENT
JULY 1992 TO OCTOBER 1992
1. Emergency Stop Switch
2. Steer Switch (Front)
3. Drive Switch
4. Speed Control
5. Steer Switch (Rear)
1
1
1 1
2
2 2
5 5
3
3 3
4
4 4
2
3
4
Figure 3-6. Remote Control Box
