SECTION 2 - PREPARATION AND INSPECTION
2-8 – JLG Lift – 3120685
26. Engine Oil Supply - Full mark on dipstick; filler cap
secure.
27. Muffler and Exhaust System - Properly secured, no
evidence of leakage.
28. Cowling and Latches, Right Side - All cowling and
latches in working condition, properly secured, no
loose or missing part.
29. Turntable Bearing and Pinion - No loose or missing
hardware; no visible damage, evidence of proper
lubrication. No evidence of loose bolts or looseness
between bearing and structure.
30. Battery - Proper electrolyte levels; cables tight, no
visible damage or corrosion.
31. Frame - No visible damage, no loose or missing
hardware (top and underside).
32. Drive Hub, Left Rear - No visible damage, no evi-
dence of leakage.
33. Wheel/Tire Assembly, Left Rear - Properly
secured, no loose or missing lug nuts, no visible
damage.
34. Drive Motor and Brake, Left Rear - No visible dam-
age, no evidence of leakage.
35. Boom Sections - No visible damage; wear pads
secure. All cylinders - rod end shafts and barrel-end
shafts properly secured.
36. Rotator and Motor - Properly secured, no visible
damage, no evidence of leakage.
37. Platform Pivot and Slave Cylinder Attach Pins -
Properly secured; evidence of proper lubrication
where applicable.
Figure 2-2. Daily Walk-Around Inspection (Sheet 3 of 3)
